  • Electric Glass Sliding Door - Modern Entrance Solution
  • Electric Glass Sliding Door - Modern Entrance Solution
  • Electric Glass Sliding Door - Modern Entrance Solution
  • Electric Glass Sliding Door - Modern Entrance Solution
Electric Glass Sliding Door - Modern Entrance Solution Electric Glass Sliding Door - Modern Entrance Solution Electric Glass Sliding Door - Modern Entrance Solution Electric Glass Sliding Door - Modern Entrance Solution

Electric Glass Sliding Door - Modern Entrance Solution

  • Product Item:HG-SD09
  • Shape:flat or curved
  • Thickness:5mm、6mm、8mm、10mm、12mm、15mm、19mm
  • Glass Type: Clear Glass, Tinted Glass, Reflective Glass, On-line Low-e Glass, Low-iron Glass
  • Size:customized
  • glass sliding door  , electric glass sliding door
    Inquiry Send Email

    Description

    <a href=https://www.hikinglass.com/Tempered-Glass.html target='_blank'>electric glass sliding door</a> - Modern Entrance Solution

    electric glass sliding door - Modern Entrance Solution

    Overview

    Electric Glass Sliding Door installed in a modern commercial lobby

    Electric glass sliding door system with sleek aluminum frame and clear tempered glass

    Our electric glass sliding door combines sleek design with advanced technology, creating the perfect entrance solution for commercial buildings, hotels, offices, and high-end residential properties. Featuring automatic operation, safety sensors, and customizable glass options, this door system offers both convenience and security—adapting seamlessly to diverse usage scenarios while elevating the aesthetic and functionality of any space.

    Key Features

    Close-up of electric glass sliding door safety sensor and aluminum frame

    Detail of safety sensors and corrosion-resistant aluminum frame

    • Automatic Operation: Smooth sliding motion with adjustable speed and opening/closing cycles, ideal for high-traffic areas where hands-free access is essential.
    • Safety First: Equipped with infrared sensors and safety edges to prevent accidents, protecting children, the elderly, pets, or users with shopping carts/wheelchairs in public spaces.
    • Energy Efficient: Optional heat-insulating (Low-E) glass reduces energy consumption by retaining indoor temperature, cutting HVAC costs in conditioned spaces.
    • Customizable Design: Available in various glass types (clear, tinted, frosted, patterned), frame finishes (anodized silver, black, white, or custom colors), and sizes to match any architectural style.
    • Easy Integration: Compatible with access control systems (keycards, biometrics, PIN codes) and building management systems (BMS) for smart, centralized control.
    • Durable Construction: High-quality aluminum alloy (6063-T5) frame with corrosion-resistant finish, withstands harsh environments (e.g., humid lobbies, outdoor vestibules).
    • Low Maintenance: Self-lubricating tracks and reliable motor system minimize upkeep, even with daily heavy use (up to 10,000 cycles/month).
    • Quiet Operation: Specialized rubber rollers and damping system reduce noise, making it suitable for quiet spaces like offices or luxury hotel lobbies.

    Detailed Application Scenarios

    Electric glass sliding doors in various settings: hotel lobby, office, hospital

    Versatile installation of electric glass sliding doors across commercial and residential spaces

    Our electric glass sliding door is engineered to meet the unique needs of multiple scenarios, blending performance with context-specific benefits:

    1. Commercial & Retail Spaces

    • Shopping Mall Entrances: Sensor-activated design eliminates manual pushing, ensuring smooth traffic flow during peak hours (e.g., weekends, sales events). Transparent tempered glass showcases storefronts, drawing in customers while maintaining security.
    • Retail Store Fronts: For boutiques, electronics stores, or supermarkets, frosted or tinted glass balances product visibility with privacy. Quick opening/closing speed reduces cold air loss—critical for grocery stores with refrigerated sections.

    2. Office & Corporate Buildings

    • Main Lobbies & Reception Areas: Creates a professional, modern first impression for clients and employees. Integration with access control systems (e.g., keycard swipes) restricts unauthorized entry, while quiet operation keeps lobbies calm.
    • Conference Rooms & Executive Suites: Compact single-panel designs fit smaller spaces, and frosted glass ensures meeting privacy without blocking natural light. Automatic closing (with adjustable delay) maintains indoor air quality and temperature.

    3. Hospitality & Leisure

    • Hotel Lobbies & Resort Entrances: Double-panel doors accommodate large groups (e.g., wedding parties, tour groups) and pair with elegant frame finishes (e.g., brushed gold) to match luxury decor. Safety sensors prevent accidents with luggage carts or strollers.
    • Spa & Gym Facilities: Water-resistant aluminum frames and easy-to-clean glass surfaces withstand humid environments (e.g., sauna-adjacent areas). Frosted glass options provide privacy for changing room entrances.

    4. Healthcare & Educational Institutions

    • Hospital Entrances & Patient Wards: Hands-free operation reduces cross-contamination (critical for infection control), while safety edges prevent injuries to patients in wheelchairs or stretchers. Durable construction stands up to frequent cleaning with disinfectants.
    • School & University Buildings: Wide-panel designs handle student crowds between classes, and infrared sensors ensure quick, safe opening to avoid bottlenecks. Low maintenance reduces downtime—essential for busy school schedules.

    5. High-End Residential Properties

    • Villa & Luxury Home Entrances: Customizable sizes (up to 3000mm height) and glass types (e.g., decorative patterned glass) complement architectural styles (modern, minimalist, classic). Integration with smart home systems (e.g., voice control via Alexa/Google Home) adds convenience.
    • Patio & Balcony Access: Weather-resistant models (with IP54-rated control boxes) withstand outdoor elements (rain, wind). Sliding design saves space compared to swing doors, making it ideal for compact balconies.

    Technical Specifications

    Technical drawing of electric glass sliding door dimensions and components

    Technical diagram showing panel dimensions, motor specs, and safety features

    Parameter Specification
    Door Type Sliding (single or double panel; optional telescopic for wide openings)
    Frame Material Aluminum alloy (6063-T5) with corrosion-resistant anodized/powder-coated finish
    Glass Options Clear, tinted, frosted, patterned, or Low-E insulated tempered glass
    Glass Thickness 8mm, 10mm, or 12mm (tempered for safety; 15mm optional for heavy-duty use)
    Panel Width Up to 1200mm per panel (custom widths available for residential/villa projects)
    Panel Height Up to 3000mm (max 3500mm for custom commercial orders)
    Opening Speed 0.4-0.8 m/s (adjustable via control box)
    Closing Speed 0.3-0.7 m/s (with soft-close function to prevent slamming)
    Power Supply AC 220V/110V, 50/60Hz (12V DC option for residential Smart home integration)
    Motor Power 150W (single panel); 300W (double/telescopic panels)
    Safety Features Infrared motion sensors (detection range: 0.5-3m), rubber safety edges, emergency stop button
    Operating Temperature -20°C to +50°C (suitable for both indoor and covered outdoor use)
    Protection Rating IP54 (control box); IP65 optional for fully outdoor installations
    Cycle Life Up to 500,000 operations (equivalent to 10+ years of daily use)

    Why Choose Our Electric Glass Sliding Door?

    Happy customer inspecting electric glass sliding door installation

    Client reviewing a custom electric glass sliding door installation in a luxury villa

    Our electric glass sliding doors are not just entrance systems—they are tailored solutions for your space’s unique needs:

    • Scenario-Specific Customization: Whether you need a weather-resistant patio door for a villa or an infection-control door for a hospital, we adjust glass type, frame material, and safety features to fit.
    • Cost-Effective Long-Term: Energy-efficient glass cuts utility bills, while low-maintenance components reduce repair costs over time.
    • Compliance & Safety: Meets international standards (e.g., EN 16005 for automatic doors, ASTM D1036 for glass safety) to ensure regulatory compliance for commercial and public spaces.
    • Aesthetic Versatility: Transparent, tinted, or frosted glass—paired with custom frame colors—blends with any interior/exterior design, from modern offices to luxury homes.

    Installation & Maintenance

    Technician installing electric glass sliding door track and motor

    Professional technician installing an electric glass sliding door system

    Professional installation is recommended to ensure optimal performance and safety. Our team provides:

    • On-site measurement to confirm custom sizes (critical for residential patios or irregular commercial openings).
    • Step-by-step installation guides (with video tutorials) for local contractors.
    • Post-installation testing (safety sensors, speed adjustment, access control integration) to ensure compliance.

    Regular maintenance (to extend lifespan) includes:

    1. Weekly: Wipe glass surfaces with non-abrasive cleaner to remove dust, fingerprints, or stains.
    2. Monthly: Inspect track for debris (e.g., dirt, small stones) and lubricate with silicone-based oil (avoid oil-based lubricants that attract dust).
    3. Quarterly: Check sensor alignment (misaligned sensors may cause false triggers or failure to open) and test safety edges.
    4. Annually: Verify electrical connections (for corrosion) and motor performance (contact support if noise or slow operation occurs).

    Ordering Information

    Ready to enhance your space with our electric glass sliding door? Contact us today for a custom quote!

    Email: sales@yourcompany.com | Phone: +1 (234) 567-890

    Contact our sales team today to:

    • Discuss your specific scenario (e.g., “hospital lobby” or “villa patio”) for tailored recommendations.
    • Request a free sample of glass types or frame finishes.
    • Get a customized quote (including shipping and installation support).
    • Access our warranty details (2-year warranty on motors; 5-year warranty on aluminum frames).

    We offer flexible lead times (10-15 business days for standard models; 20-25 days for custom designs) and global shipping to over 50 countries.
