China Top quality toughened glass factory HG-T02

Description

Top quality tempered glass manufacturer in China HG-T01

Glass Type	Clear Glass, Tinted Glass, Reflective Glass,
	On-line Low-e Glass, Low-iron Glass
Craft	Tempered Glass, Heat Strength Glass,
	Heat Soaked Glass
Color	Blue, Green, Bronze, Gray,Golden etc.
Thickness	5mm、6mm、8mm、10m
	m12mm、15mm、19mm
Max Size	Flat Glass:2440*6000mm
	Curved Glass:1000x2000mm
Min Size	Flat Glass:300x300mm
	Curved Glass:300*300mm
Certificates	CE & CCC & CSI

Why choose us:

1. Can accept small quantity order

2. Accept customized

3. Handle optional

4. Towel rack optional (with/without)

5. Glass self-cleaning (more selling points)

6. Contains installation hardware (convenient installation and more thoughtful)

7, with installation instructions (conform European and American habits)

8. Square tube/round tube/stainless steel/wire drawing and gloss (more abundant products)

9. Carton packaging (Both project and supermarket)

1. Production process

Cutting-edging-rounded corners-water jet-punching-silk screen-tempering-self-cleaning liquid / safety explosion-proof film-packaging

Cut Two edges grinding

Round Corner Machine hole puncher

curve tempered glass Bathroom door

Glass film

Nano self-cleaning liquid

2. Quality Control

2.1 Each glass must be inspected to confirm before entering the factory;

2.2 Quality control in the production process are in accordance with quality control standards.

First inspection-self-inspection-special inspection-factory inspection, product standards are strictly implemented in accordance with customer technical documents or industry standards;

2.3 The dimensional accuracy and tempering quality inspection data of processed products shall be recorded and archived with traceability;

2.4 The bending degree of toughened grain is tested, the bending degree is 1.5‰, and the grain size is 55-80 grains per 50*50mm

3. The company's certification qualifications

The company's products have passed European CE certification and American SGCC certification

4. 10years of export packaging experience: Carton foam packaging and fumigation-free wooden box packaging can be realized to ensure product transportation safety;

5. The company's equipment processing capacity

Focus on the manufacture of tempered glass for home appliances for 14 years. The company has comprehensive equipment capabilities for processing high-temperature silk screens, including Italian Bottero cutting machines, Bottero edging machines, CNC machining centers, automatic punching machines, automatic rounding machines, automatic screen printing machines, tempering furnaces and other equipment.

-Choose Taiwan Glass or Jinjing Automotive Grade Original Float glass

-Polished straight edges, size tolerance ±1mm, uniform edge 1mm

-Safety corner or round corner treatment

-Water jet cutting, accurate size, vertical water jet with safety angle,

-Even tempered grain

-Fumigation-free wooden box packaging, firm and safe

-Can provide carton foam sales packaging

-Self-cleaning nano coating can be applied

-Safety explosion-proof film can be attached

Glass processing range:

Thickness: 3mm, 3.2mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm

Glass color: chear glass, ultra clear glass, tinted glass,reflective glass

Edging: straight edge, round edge

Tempering: C shape and J shape

Silk screen: high temperature screen printing, frosted screen printing

shower room: shower room assembly

Other processes: can be coated with nano self-cleaning liquid (from Germany, 10-year warranty),

Safety explosion-proof film can be attached

Packing: plywood wooden box and carton + foam separate sales packaging

Toughened  Glass manufacturer with compressive stress on the surface. Also called strengthened glass. The use of tempering method to strengthen the glass began in France in 1874. Tempered glass belongs to safety glass. Toughened glass is actually a kind of prestressed glass. In order to improve the strength of glass, chemical or physical methods are usually used to form compressive stress on the surface of the glass. When the glass is subjected to external force, the surface stress is first offset, thereby increasing the bearing capacity. Ability to enhance the glass's own resistance to wind pressure, cold and heat, and impact. Pay attention to distinguish it from FRP.

characteristic

safety

When the glass is damaged by external force, the fragments will become small particles with obtuse angles similar to honeycombs, which are not easy to cause serious harm to the human body.

high strength

The brunt stoutness of moderate hourglass of the same stratum is 3 to 5 set that of customary hourglass, and the crooking stoutness is 3 to 5 clock that of usual looking-glass.

Thermal stability

Toughened  Glass factory has good thermal stability, can withstand a temperature difference of 3 times that of ordinary glass, and can withstand a temperature difference of 300°C.

advantage

The first is that the robustness is several set higher than that of regular spyglass, and it is resisting to reclination.

The second is safe use. The increased load-bearing capacity improves the fragile nature. Even if the toughened glass is damaged, there are small fragments without acute angles, which greatly reduces the damage to the human body. The quenching and heating resistance of toughened glass is 3 to 5 times higher than that of ordinary glass, and it can generally withstand temperature changes of more than 250 degrees, which has a significant effect on preventing thermal cracking. It is a kind of safety glass.To insur the safeness of eligible materials for dear-mount buildings.

Disadvantage

Disadvantages of tempered glass:

1. The Toughened  Glass supplier cannot be cut and processed anymore, and the glass can only be processed to the required shape before tempering, and then tempered.

2. Although the strength of tempered glass is stronger than ordinary glass, tempered glass has the possibility of self-explosion (breaking by itself), while ordinary glass has no possibility of self-explosion.

3. There will be unevenness (wind spots) on the surface of the tempered glass, and there will be a slight thickness thinning. The reason for the thinning is that after the glass is melted and softened, it is quickly cooled by strong wind, so that the crystalline hiatus nature the goblet fall smaller and the stamp turn larger, so the weatherglass is thinner after tempering than before.In general, 4~6mm glass becomes 0.2~0.8mm thinner after tempering, and 8~20mm glass becomes 0.9~1.8mm thinner after tempering. The specific level depends on the equipment, which is why tempered glass cannot be used as a mirror.

4. The flat glass used in construction after passing through the tempering furnace (physical tempering) is generally deformed, and the degree of deformation is determined by the equipment and technical personnel. To a undoubting compass, it act on the ornamental sign (except for appropriate necessarily).
